Automotive Database: Volkswagen Polo Mk2

Volkswagen Polo Mk2

Volkswagen Polo Mk2
Overview
Also called	Volkswagen Derby
Production	1981–1994
Body and chassis
Class	Supermini
Body style	3-door hatchback 3-door hatchback (coupé) 2-door sedan
Platform	Volkswagen Group A02
Chronology
Predecessor	Polo Mk1
Successor	Polo Mk3

The Volkswagen Polo Mk2 is the second generation of the Volkswagen Polo supermini, it was produced from late 1981 until 1994. It received a major facelift in 1990 and was available in three different bodystyles, including a controversial "kammback"-styled hatchback.

Polo Mark 2

Volkswagen Polo Mk2

Volkswagen Polo Mk2
Overview
Also called	Volkswagen Derby (sedan version only)
Production	1981–1990
Assembly	Wolfsburg, Germany Pamplona, Spain
Body and chassis
Class	Supermini
Body style	3-door hatchback 3-door hatchback (coupé) 2-door sedan
Platform	Volkswagen Group A02
Chronology
Predecessor	Polo Mk1
Successor	Polo Mk2F

A revised Polo model (known as the Mark 2 or Mark II, internally designated Typ 86C) was introduced in October 1981, with the major change being the introduction of a new body style with a steep (almost vertical) rear window, as well a version with a diagonal rear window and a similar profile to the previous model. These two body styles were called the Hatchback and Coupé respectively, although in fact both were three-door hatchbacks. The latter was added to the range in 1983 as the radical styling of the original design was not welcomed by all. The Coupé was originally only available with the more powerful engines (55 and 75 PS), but after a mild facelift in August 1984 the base 40 PS (29 kW) unit was also made available.

The sedan version was no longer called the Derby in all countries, and was changed to the Polo Classic. Production was expanded to Spain in the mid-1980s following Volkswagen's takeover of SEAT.

1093 cc or 1272 cc engines were available at launch. In 1986, the Polo received numerous technical improvements; amongst many other minor updates, the engines were changed to lower maintenance hydraulic tappets, new camshafts and valve gear and an automatic choke; the 1043 cc engine replaced the 1093 cc, and in some markets the 1.3 litre engine was available with fuel injection and equipped with a catalytic converter. In 1984 an all-new 1.3 litre engine was introduced, which was used in various generations of Polo until 1996. The Polo received some changes in August 1984, including a new dashboard, a bigger fuel tank, and more standard equipment. The GL was discontinued with the CL essentially taking its place. All models now received round rather than the earlier square headlights.

Available with the 1093 cc engine the Coupé featured additions such as sporting seats trim, wheel arch extensions, rear spoiler, low profile tyres and a rev counter, as well as the round headlights which were later fitted across the range. The GL featured a 60 PS (44 kW) engine. In 1985, the first sporty Polo, the Coupé GT, was introduced with a 75 PS (55 kW) engine, as well as servo assisted brakes, twin headlights, a digital clock, sports seats and a rev counter. Other special feature models were introduced over the rest of the period of the Mark 2 production run including models such as the Twist, Parade and Country.

Mk2 Derby saloon (1981-1984)

The Mark 2 Polo was used extensively by Volkswagen to develop future innovations, for example supercharging. The supercharger-equipped GT G40 version was introduced in 1987, in LHD Coupe form only, first as a limited batch of about 500 cars, most of which were sold to VW workers (as a homologated version of the car for the G40 Cup race series) and later as a normal production version. This model featured the 1272 cc engine with a small bore G-Lader supercharger, giving 113 PS (83 kW) at 6000 rpm, as well as modified suspension and the bodywork of the "normal" GT Coupé. The car could reach 100 kilometres per hour (62 mph) in 8.1 secs from and had maximum speed of 196 kilometres per hour (122 mph) it was used by VW to set a number of world endurance speed records — such as the 1300 cc class records for speed over 24 hours and speed over a distance of 5000 km. A G-Lader would later be used on the larger and more technically challenging G60 engine used in the Golf and Corrado.

An extremely fuel-efficient two-cylinder diesel was prototyped in the mid-1980s with a G40 supercharger to overcome its small capacity, although this did not make production. A high-fuel-efficiency model which did make production was Formel E (E for Economy), introduced in 1983. This used a high-compression 1272 cc engine, longer gear ratios and an early-stop-start ignition system (called SSA) that would cut the engine when idle for more than two seconds to save fuel whilst temporarily stopped in traffic, and restart the engine when the gear lever was moved to the left in neutral. The system could be enabled or disabled by means of a toggle switch below the light switch. Similar systems were later used on the Volkswagen Golf Mk3. Similar systems were developed by other car manufacturers.

Engines

The Mark 2 was available with the following engines:

1.1 1093 cc 4-cylinder petrol engine (1981–1983)
1.3 1272 cc 4-cylinder petrol engine. (1981–)
1.0 1043 cc 4-cylinder petrol engine (1983–)
1.3 1272 cc 4-cylinder petrol engine with fuel injection and equipped with a catalytic converter. (1991–)
1.3 1272 cc 4-cylinder supercharged petrol engine with 133 PS (GT G40 version 1987 only)
1.3 L 4-cylinder diesel engine (1986–1990)
1.4 L 4-cylinder diesel engine (1990–)

Trim levels

The VW Polo was available in five trim levels;

Fox (1.0, 1.3 petrol, 1.3 diesel), from August 1984
C (1.0, 1.1 petrol, 1.3 diesel)
CL (1.0, 1.1, 1.3 petrol, 1.3 diesel)
GL (1.1, 1.3 petrol, 1.3 diesel)
GT (1.3 petrol)

For the 1985 model year, the GL was dropped and the bargain limited edition "Fox" model was introduced in some markets. In the UK, the spartanly equipped Fox arrived in 1987, available only with a 1.0-litre engine. It was also sold with the 1.3 and as a diesel version in Europe. However, neither the 1.3 petrol nor the diesel engines were available in the UK. Otherwise, versions sold on the Continent were similar to their UK counterparts; this was the same for all Polo Mark 2 versions up to the 1994 redesign.

Polo Mark 2 facelift (1990-1994)

1992 Volkswagen Polo Coupé

Volkswagen Polo Mk2F (86C)
Overview
Also called	Volkswagen Derby
Production	1990–1994
Body and chassis
Class	Supermini
Body style	3-door hatchback 3-door hatchback (coupé) 2-door sedan
Platform	Volkswagen Group A02
Chronology
Successor	Polo Mk3

1994 Mk2F Polo hatchback (UK-Spec)

A facelift in 1990 (referred to unofficially as the Mark 2F or IIF) saw square headlights, bigger bumpers and a new interior (dash and door trim). The three different styles (hatchback, coupé hatchback and sedan) were maintained. As well as the cosmetic differences, under the skin the car received modifications to the chassis and suspension as well as the addition of servo-assisted brakes to all models including right hand drive versions. The new Polo still had the 4-cylinder engine but now as well as the carburetor 1.0 L, a fuel injection model was available with single-point injection and all engines came standard with a catalytic converter to combat tightening EU laws on automobile emissions.

The Derby was only produced in Spain, and ceased production in 1992. At this point, the Polo was now terminally dated. The follow-up model, the Mark 3 or Typ 6N version, was already well developed, but due to the high sales numbers, production of the other Polo models (hatchback and Coupé) was continued to 1994 in Wolfsburg and Spain. Volkswagen used the extra two years to restudy the Typ 6N and change the format slightly before introduction in 1994.

Soon after the launch of the Mark 2F, another sporting model was added to the range — a new version of the supercharged G40, now as a full production model in all markets rather than the limited batch of Mark 2 G40s. The engine used a slightly different version of the digifant injection system to allow the use of a catalytic converter, and produced 113 PS (83 kW), which gave 0–100 km/h figures of 8.6 seconds and a top speed of 196 kilometres per hour (122 mph). The car was lowered by 25 mm (1.0 in) over the standard Polo and featuring special edition Le Mans sports seats, similar exterior styling to the GT with the addition of a bee sting aerial and 5.5J X 13" BBS RA cross spoke alloy wheels. As with the previous model, VW Motorsport modified G40 Cup cars were sold for racing in a one-make series, the Volkswagen Polo G40 Cup. The reliability of these vehicles was hampered by early production mistakes and high maintenance costs — parts of the G-Lader can wear out quickly if unmaintained — which damaged the reputation of the supercharging concept. Volkswagen ended its experimentation with supercharged hot hatches at the end of the Polo 2F production run, due to high manufacturing costs and less than enthusiastic sales. The price was little less than that of the basic Golf GTI.

In 1992 VW released a limited number of special edition Polos, with special trim and a G40 engine and suspension. The "Genesis" G40 was made to special order only. A single right hand drive example found its way to the UK. This one-off model was a competition prize when the VW-sponsored Genesis tour reached its UK leg.

Trim levels

Trim levels were Fox, CL, GL, Boulevard and Genesis. The Fox was the entry-level model, only available with a 1.0-litre engine, but in Europe it had a 1.3-litre version.
